Smart Wifi Access Control (Wifi + EM + MF) | XAC-MSLCF3

Name: Smart Wifi Access Control (Wifi + EM + MF) | XAC-MSLCF3
Brand: Viskou | One-Stop Tech Solutions for a Smarter Future
SKU: VMMC000019
Price: 142 MYR
Availability: InStock

XAC-MSLCF3

- Doorbell Call Notice.
- Can set time restriction for users.
- Remotely access (supports 3G/4G/5G).
- Multiple access modes: Smartphone, card, PIN, fingerprints. (For CF3-WIFI only).

RM142.00 ~~RM284.00~~

(Excluding Taxes)

Quantity

-

+

57 In Stock, Puchong

6 In Stock, Johor Bahru

10 In Stock, Penang (Perai)

9 In Stock, Penang (Gelugor)

0 In Stock, KK

Add to Favorite Items

Description

XAC-MSLCF3
Smart Wifi Access Control (Wifi + EM + MF)

Product Specifications

Parameters	Specifications
User Capacity	Hardware User: 10000 App User: 500
Common User	500 Finger + 9988 PIN/Card Users
Panic User	2
Visitor User	10
PIN Length	4-6 digits
Operating Voltage	12-18V DC
Idle Current	< 60mA
Active Current	≤150mA
Proximity Card Reader	EM or Mifare
Radio Technology	125KHz/13.56MHz
Read Range	2-6cm
Wiring Connections	Relay output, exit button, alarm, door contact, Wiegand input/output
Relay	One (NO, NC, Common)
Adjustable Relay Output Time	0~99 Seconds (5 seconds default)
Lock Output Load	2 Amp Maximum
Wiegand Interface	EM card version: Wiegand 26~44 bits input & output (Factory default: Wiegand 26bits) Mifare card version: Wiegand 26~44 bits,56bits,58bits input & output (Factory default: Wiegand 34bits) 4 bits,8bits (ASCII),10 digits Virtual Number(Factory default:4bits)
Environment	Meets IP66
Operating Temperature	(-30°C ~ 60°C) (-22°F ~ 140°F)
Operating Humidity	0%RH ~ 98%RH
Physical	ABS
Color	Black
Dimensions	L150 x W45 x H21.5 (mm)
Unit Weight	170g
Shipping Weight	270g

Datasheet

Download Datasheet
