AX6600 Wi-Fi 6 Triple Radio Ultra-High Speed Density AP | AP661

Name: AX6600 Wi-Fi 6 Triple Radio Ultra-High Speed Density AP | AP661
Brand: Viskou | One-Stop Tech Solutions for a Smarter Future
SKU: 02355VFC
Price: 1830 MYR
Availability: InStock

AP661

- Management by HUAWEI eKit App
- SPEED: 575Mbps at 2.4 GHz, 6 Gbps at 5 GHz
- MU-MIMO,Smart Antenna,Automatic Radio Calibration,Cloud Management,Bluetooth BLE 5.2

RM1,830.00 ~~RM3,660.00~~

(Excluding Taxes)

Quantity

-

+

6 In Stock, Puchong

2 In Stock, Johor Bahru

0 In Stock, Penang (Perai)

0 In Stock, Penang (Gelugor)

0 In Stock, KK

Add to Favorite Items

Description

AP661
AX6600 Wi-Fi 6 Triple Radio Ultra-High Speed Density AP

Management by HUAWEI eKit App
Speed: 575Mbps at 2.4 GHz, 6 Gbps at 5 GHz
PoE power supply: in compliance with IEEE 802.3af
MU-MIMO,Smart Antenna,Automatic Radio Calibration,Cloud Management,Bluetooth BLE 5.2
PORT: 1 x 10M/100M/GE/2.5GE electrical port, 1 x 10M/100M/GE electrical port, 1 x USB port

Product Specifications

	Installation mode	Wall mounting Ceiling mounting T-rail mounting
	Dimensions (diameter x height)	Φ 220 mm x 50 mm
	Weight	1.08 kg
	Port	1 x 10M/100M/GE/2.5GE electrical port 1 x 10M/100M/GE electrical port Huawei eKitEngine AP661 Access Point Datasheet 10 Item Description 1 x USB port NOTE : l The 2.5GE port supports PoE-In. If the BOM code is 02353XBQ, the port is a GE port.
Power supply specifications	Power input	DC: 12 V ± 10% PoE power supply: in compliance with IEEE 802.3at
Power supply specifications	Maximum power consumption	21.2 W (excluding USB) NOTE : The actual maximum power consumption depends on local laws and regulations.
Environmental specifications	Operating temperature	–10°C to +50°C (From 1800 m to 5000 m, the maximum operating temperature of the device decreases by 1°C for every 300 m increase in altitude.)
	Storage temperature	-40°C to +70°C
	Operating humidity	5% to 95% (non-condensing)
	Altitude	–60 m to +5000 m
	Atmospheric pressure	53 kPa to 106 kPa
Radio Specifications	Antenna type	Built-in smart antenna
	Antenna gain	2.4 GHz: 4 dBi 5 GHz: 5 dBi NOTE : The preceding gains are the peak gains of a single antenna.
	Maximum quantity of SSIDs	≤ 16
	Maximum number of access STAs	≤ 1536 (512/radio) NOTE : The actual number of users varies according to the environment.
	Maximum transmit power	2.4 GHz: 25 dBm (combined power) 5 GHz (2x2 MIMO): 23 dBm (combined power) 5 GHz (4x4 MIMO): 26 dBm (combined power) BLE: < 10 dBmThe actual transmit power varies according to local laws and regulations.
	Power adjustment increment	1dBm

Datasheet

Download Datasheet
