Wired internal 18m PIR detector | DS-PDP18-EG2

Name: Wired internal 18m PIR detector | DS-PDP18-EG2
Brand: Viskou | One-Stop Tech Solutions for a Smarter Future
SKU: 314300611
Price: 48 MYR
Availability: InStock

DS-PDP18-EG2

- Creep-zone protection
- Up to 18m detection range
- Wall and ceiling mount options
- 9 to 16 V wide voltage adaptation

RM48.00 ~~RM96.00~~

(Excluding Taxes)

Quantity

72 In Stock, Puchong

20 In Stock, Johor Bahru

5 In Stock, Penang (Perai)

15 In Stock, Penang (Gelugor)

2 In Stock, KK

Add to Favorite Items

Description

DS-PDP18-EG2
Wired internal 18m PIR detector

Wide voltage - 9 to 16 V wide voltage adaptation with polarity reverse connection protection
Automatic sensitivity - self-adapts to changing environmental conditions to maintain stability and intruder catch performance
Creep-zone protection - covers the blind spot area directly below it, where an intruder may have otherwise avoided detection
Detection range - Up to 18m volumetric detection coverage, the Ellipse is the ideal solution for any small to large indoor rooms and spaces.
Wall and ceiling mount options - can be fitted at a mounting height of 1.8m to 2.4m. There is also a ceiling mount option available if required
3D optics - Improves the detection of moving targets; ensuring more precise signals can be received from the PIR by enabling the perfect focusing of the infra-red signal onto the pyro-electric sensor
IFT technology - automatically adjust the upper and lower alarm trip thresholds when exposed to electromagnetic or electrical interference and shift the thresholds before the detector goes into false alarm
Selectable EOL resistors - incorporates selectable alarm resistor values of 1K, 2K2, 4K7, 5K6 and 8K2, as well as tamper resistance values of 1K, 2K2, 4K7 and 5K6; catering for most control panels on the market

Specifications

Detection performance	Detection Range	18 m
	Detection Angle	85.9°
	Sensitivity adjustment	High, Auto, Low
Software features	Tamper-Proof	Front
Hardware features	Indicator	Blue (alarm)
Electrical characteristics	Power supply	9 to 16 VDC (standard: 12 VDC)
Electrical characteristics	Power Consumption	11mA quiescent, 8mA Alarm
General	Dimension (W x H x D)	65.4mm x 86.8mm x 45.5mm
	Weight	68 g
	Application scenario	Indoor
	Installation height	1.8 to 2.4 m
	Bracket	Optional wall & ceiling accessory

Datasheet

Download Datasheet
